MLTX2™ Transmitter
Bellybox Transmitters
Our MLTX2™ bellybox transmitter incorporates the latest electronic technology in a lightweight, comfortably contoured, yet durable case. It’s available with several customizable options to provide the ideal solution for a variety of applications and industries; including Crane and Hoist, Fluid Power, and Surface Mining applications.
Features and Benefits
Features & Benefits
COMFORTABLE & PRACTICAL DESIGN
Ergonomically designed contoured case is more comfortable for the user. One of the lightest bellybox transmitters available today—50% lighter than other bellybox transmitters. Easy to use, angled lever or joystick controls enhance operator comfort. Choose up to 7 levers or 3 joysticks; up to 12 toggles; mushroom E-stop.
DURABLE & RELIABLE
Rugged, super-tough nylon housing is made to withstand shock. Rated NEMA 4 (IP66), sealed to withstand harsh, industrial environments. Synthesized frequency generation enhances reliability. Access code system provides peace-of-mind, as the signal only operates the intended equipment. Designed to minimize power consumption, providing one of the longest life batteries in the industry today — rechargeable NiMH battery pack is optional.
Options
VERSATILE AND FEATURE-RICH OPTIONS
- Configure the MLTX2 on a Windows PC with the optional Radio Control Programmer (RCP) via USB or the USB/IR adapter
- Easily upload new programming in the field with USB connection
- Optional graphic display keeps the operator informed of system status at all times, and makes configuring access codes, channels, and other system setting simple
- Two-way feedback available, showing maching related parameters, engine diagnostic information. Received Signal Strength Indication (RSSI), and much more
- Several frequency options including 400MHz, 900MHz, and 2.4GHz
- Backward compatible with most existing Telemotive systems
Synthesized RF technology available for:
- Unlicensed (FCC Part 15/RSS-210)
- Licensed (FCC Part 90/RSS-119)
- Available with ATEX and IECEx approvals for Zone 0, Zone 1, and Zone 2 applications
- ATEX Approval: II 1 G Ex ia IIC T3/T4 Ga
- IECEx Approval: Ex ia IIC T3/T4 Ga
Antenna Installation and Troubleshooting Guide
Download the free guide from our tranining team to ensure proper antenna installation. And keep the guide handy for useful troubleshooting steps if needed.
IDEAL FOR THE FOLLOWING APPLICATIONS:
Engineered-to-Order Application Questionnaires
Work directly with our Engineered-to-Order team on a radio application by filling out this questionnaire.
Get started on an Engineered-to-Order mobile hydraulic application by filling out this questionnaire today.
