Quattro®, the revolutionary green solution for yesterday’s and today’s tallest buildings, is the latest evolution in Magnetek’s line of technologically advanced, Energy Engineered®  elevator drives.

Features and Benefits

Save energy and money while improving reliability with our energy regenerative controls for new installations and elevator modernization projects. Magnetek-brand Elevator Drives will help transform your building into a facility that measures up to modern buildings in functionality, comfort, and energy savings.

Learn More About Elevator Modernization

Updating older elevators to modern technology can significantly reduce energy costs. DC elevator machines that are properly maintained and in good working order can provide excellent ride quality and years of additional service.

Stay in the game with a DC Motor Evaluation

Features and Benefits

Quattro® AC Elevator Drive

Regeneration Means Energy Savings

Quattro consumes the lowest energy possible, and installing Quattro can help your project qualify for utility energy rebates.

Familiar Interface for Easy Setup

Setup and adjusting Quattro is easy because it uses Magnetek's familiar control interface that has been designed into our HPV® AC elevator drives installed worldwide.

Superior Ride Quality

Quattro's precise, accurate control provides smooth acceleration and deceleration, resulting in superior ride quality. These same proven control algorithms operate Magnetek DC drives installed in some of the world's tallest buildings.

Options

OPTIONS:

  • Regenerative Power Conversion for AC Motors
  • Clean Utility Side Harmonics (<8% THDI)
  • Near Unity Power Factor (P.F.>0.95)
  • Multiple Input Voltage Ranges
  • - 200-480 VAC, 50/60 Hz
  • Elevator Rated
    • - 250% Overload
    • - 45° C Amb. (Exterior to Cabinet)
  • Internal or External Velocity Reference Controls
  • Provision for:- Independent Disable of Power- Output Power Contactors
  • Meets
    • - ASME A17.1-2000. 2.26.9.6
    • - EN12015 (Emissions)
    • - EN12016 (Immunity)
    • CSA Certified
  • Designed for 80,000 Hours of Elevator Duty
