Features and Benefits

Magnetek's ergonomically styled Mini-MBT bellybox transmitter is one of the smallest and lightest bellybox controls available on the market today. It offers much of the control capability found in our larger bellybox transmitters, including proportional joysticks, toggle switches, potentiometers, graphic display, two-way feedback, and FHSS RF, yet fits easily in an operator's hands.

This versatile transmitter incorporates the latest electronic technology to meet the needs of a variety of applications and industries, including stationary concrete pumps, jib cranes, monorail hoists, work station cranes, stump grinders, and tire handlers.

STYLE AND COMFORT IN ONE PACKAGE

Ergonomic design easily fits in your hands and feels similar to gaming controllers
Convenient metal belt clip secures to your waist, or carry over your shoulder with Magnetek’s deluxe padded strap

ADAPTS TO YOUR SPECIFIC APPLICATION

• Select up to 10 toggle switches
• Numerous combinations of toggles, selector switches, and potentiometers
• Available with proportional controls
• CAN-bus pendant option available
• Custom engraving on transmitters per application
• Optional haptic feedback available

DEPENDABLE AND RELIABLE

• Rugged, super-tough nylon housing is made to withstand shock
• Rated NEMA 4 (IP66), sealed to withstand harsh, industrial environments
• Available with Frequency Hopping Spread Spectrum (FHSS), reliable in extreme RF conditions
• Long-lasting battery is designed to minimize power consumption
• Military grade auxiliary function switches

VERSATILE AND FEATURE RICH

• Optional LCD screen displays easy-to-read system diagnostics
• Available two-way RF for applications requiring feedback
• Several frequency options including 400MHz, 900MHz, and 2.4GHz
• Synthesized RF technology available
• Unlicensed (FCC Part 15/RSS-210)
• Licensed (FCC Part 90/RSS-119)
• Available high power RF for long range or harsh environments
• Optional Radio Control Programmer (RCP) connects via USB, allowing you to program settings from your Windows PC
